REGISTRATION:

OWNER: TOBIAS, INC

OPERATOR: TOBIAS, INC.

OFFICIAL NO. : 1196546

NUMBER IN CREW:  4

BUILDER: BREAUX’S BAY CRAFT, INC.

YEAR: 2007

HULL: ALUMINUM

USCG  CERTIFIED FOR 200 MILES OFFSHORE

PORT OF ERATH, LA

GENERAL INFORMATION:

DIMENSIONS:  165’x 30’x13’

CLEAR DECK SPACE:  100’x 26’

DECK CARGO CAPACITY:   275 TONS

GROSS TONNAGE:   99 TONS

PROPULSION:

MAIN ENGINES: (4) 3512 CATERPILLAR

TOTAL HP:   6300

REDUCTION GEAR:   TWIN DISK 2.47:1

STEARING:   HYDRAULIC DUAL PUMPS

GENERATORS:   (2) 80KW JOHN DEER

VESSEL SPEED:   31 KNOTS –LIGHT SHIP

        27 KNOTS –LOADED

BOW THRUSTER: THRUSTMASTER 30” TUNNEL

                                 POWERED BY CATERPILLAR 3306B

STEARN CONTROLS

LIQUID AND PUMPING CAPACITIES :

FUEL GALLONS : 16,500

POTABLE WATER GALLONS: 40,000

LUBE OIL: 600 GAL

ACCOMMODATIONS

CERTIFIED TO CARRY 75 PERSONS

CREW BERTHS:   8

GALLY:   FULLY EQUIPPED

DYNAMIC POSITIONING: (DP1)

BEIER IVCS 2000

MFG:  BEIER RADIO

NAVAGATIONAL  AND COMMUNICATION EQUIPMENT:

(2) SSB STEVENS SEA 235 RADIOS

(3) STANDARD QUEST VHF RADIOS

STANDARD VLH-3000 HAILER SYSTEM

FURUNO NX-300 PAPERLESS NAVTEX

(2) RADARS – FURUNO FR 8122

FURUNO GP-7000 COLOR PLOTTER

SPECIAL FEATURES:

CLOSED CIRCUIT TV SYSTEM WITH VIDEO CAMERAS

CATERPILLAR C9 ENGINE DRIVEN FIRE PUMP 1100 GPM

500 GALLON WASTE OIL TANK

CONTACT:

TOBIAS INC.

PO BOX 130

ERATH, LA  70533

PHONE:  337-937-6802

FAX :  337-937-0661
